MILTON INDUSTRIES

S-685-6 Air Manifold3-in-1 air manifolds, lightweight, aluminum body. Supply 3 air tools from a single outlet. No need to disconnect and connect for every tool change. 3/8" inlet NPT Female x 1/4" (3) outlets NPT Female. No. S-685-6: Material: Aluminum, Inlet Size: 3/8" FPT, Outlet Size: 1/4" FPT

S-783 Milton 1/4 In. Body Series T-Style Plug SKU # 583030T-Tru-Flate/Parker interchange series 1/4" basic size. Plugs are case hardened steel-plated to resist rust. For use with shop air. No. S-783: Design: T-Style, Thread Size: 1/4" FMPT, Material: Steel-Plated, For Use With: T-Style No. S-784: Design: T-Style, Thread Size: 1/4" FNPT, Material: Steel-Plated, For Use With: T-Style

S733 Milton 3/8 In. Body Series M-Style Plug3/8" NPT Male. Case hardened steel. Plated to resist rust. Maximum inlet pressure: 300 P.S.I. Maximum temperature: 250 deg.. Air flow: 40 SCFM. Will interchange with all manufacturers who comply with the dimensional requirements of military specification MIL-C-4109. 2 per card. For use with shop air. No. S733: Design: M-Style, Thread Size: 3/8" MPT, Material: Steel-Plated, For Use With: M-Style

S-1818 Milton 1/2 In. Body Series G-Style PlugG-style plug. Requires over 60 SCFM (standard cubic feet per minute). Maximum temperature: 250 degrees Fahrenheit. Air flow: 99 SCFM. Maximum inlet pressure: 300 psi (pounds per square inch). Buna-N seals. No. S-1817: Design: G-Style, Thread Size: 1/2" MNPT, Material: Case Hardened Steel, For Use With: G-Style, Pkg Qty: 1, Package Type: Card No. S-1818: Design: G-Style, Thread Size: 1/2" FNPT, Material: Case Hardened Steel, For Use With: G-Style,...

S-611-4 Full Swivel Hose Fitting Plug SKU # 582738Male full swivel prevents hose from kinking. Constructed of brass material ensures durability. No. S-611-4: Design: Full Swivel, Thread Size: 1/4" MPT x 1/4" Swivel, Material: Brass, For Use With: 1/4" Thread

S-1839 Milton H-Style Plug SKU # 583111H-style industrial interchange series. Plugs are case hardened steel-plated to resist rust. 2 per package. For use with shop air. No. S-1837: Design: H-Style, Thread Size: 3/8" NPT Male, Material: Steel-Plated, For Use With: H-Style No. S1838: Design: H-Style, Thread Size: 3/8" NPT Female, Material: Steel-Plated, For Use With: H-Style No. S-1839: Design: H-Style, Thread Size: 1/4" NPT Male, Material: Steel-Plated, For Use With: H-Style ...

S-784 Milton 1/4 In. Body Series T-Style Plug SKU # 583032T-Tru-Flate/Parker interchange series 1/4" basic size. Plugs are case hardened steel-plated to resist rust. For use with shop air. No. S-783: Design: T-Style, Thread Size: 1/4" FMPT, Material: Steel-Plated, For Use With: T-Style No. S-784: Design: T-Style, Thread Size: 1/4" FNPT, Material: Steel-Plated, For Use With: T-Style

S-1817 Milton 1/2 In. Body Series G-Style PlugG-style plug. Requires over 60 SCFM (standard cubic feet per minute). Maximum temperature: 250 degrees Fahrenheit. Air flow: 99 SCFM. Maximum inlet pressure: 300 psi (pounds per square inch). Buna-N seals. No. S-1817: Design: G-Style, Thread Size: 1/2" MNPT, Material: Case Hardened Steel, For Use With: G-Style, Pkg Qty: 1, Package Type: Card No. S-1818: Design: G-Style, Thread Size: 1/2" FNPT, Material: Case Hardened Steel, For Use With: G-Style,...

S-778 Milton 1/4 In. Body Series A-Style Plug SKU # 583023A-Style plugs are case hardened steel and plated to resist rust. Plug has a maximum inlet pressure of 300 pound per square inch. No. S-777: Design: A-Style, Thread Size: 1/4" MPT, Material: Steel-Plated, For Use With: A-Style No. S-778: Design: A-Style, Thread Size: 1/4" MPT, Material: Steel-Plated, For Use With: A-Style

728 Milton M-Style Plug SKU # 570589M-Style, hardened steel plated plug. Rust resistant. Basic flow size: 40 SCFM (standard cubic feet per minute). Complies with military specifications MIL-C-4109. Interchangeable with all manufacturers who comply with the dimensional requirements of military specification MIL-C-4109. No. S-727: Design: M-Style, Thread Size: 1/4" Male NPT, Material: Steel-Plated, Pressure Rating: 300 psi, Air Rating: 40 SCFM, Pkg Qty: 2, Package Type: Card No. S-728: Design:...

727 Milton M-Style Plug SKU # 570576M-Style, hardened steel plated plug. Rust resistant. Basic flow size: 40 SCFM (standard cubic feet per minute). Complies with military specifications MIL-C-4109. Interchangeable with all manufacturers who comply with the dimensional requirements of military specification MIL-C-4109. No. S-727: Design: M-Style, Thread Size: 1/4" Male NPT, Material: Steel-Plated, Pressure Rating: 300 psi, Air Rating: 40 SCFM, Pkg Qty: 2, Package Type: Card No. S-728: Design:...

S1838 Milton H-Style Plug SKU # 583096H-style industrial interchange series. Plugs are case hardened steel-plated to resist rust. 2 per package. For use with shop air. No. S-1837: Design: H-Style, Thread Size: 3/8" NPT Male, Material: Steel-Plated, For Use With: H-Style No. S1838: Design: H-Style, Thread Size: 3/8" NPT Female, Material: Steel-Plated, For Use With: H-Style No. S-1839: Design: H-Style, Thread Size: 1/4" NPT Male, Material: Steel-Plated, For Use With: H-Style ...

S-728 Milton M-Style PlugM-Style, hardened steel plated plug. Rust resistant. Basic flow size: 40 SCFM (standard cubic feet per minute). Complies with military specifications MIL-C-4109. Interchangeable with all manufacturers who comply with the dimensional requirements of military specification MIL-C-4109. No. S-727: Design: M-Style, Thread Size: 1/4" Male NPT, Material: Steel-Plated, Pressure Rating: 300 psi, Air Rating: 40 SCFM, Pkg Qty: 2, Package Type: Card No. S-728: Design: M-Style,...

S-1809 Milton P-Style Plug SKU # 570350P-style plug constructed of case hardened steel plated to resist rust. Maximum temperature: 250 degrees Fahrenheit. Air flow: 68 SCFM (standard cubic feet per minute). Maximum inlet pressure: 300 psi (pounds per square inch). No. S-1809: Design: P-Style, Thread Size: 1/4" MNPT, Material: Case Hardened Steel, Pressure Rating: 300 psi, Air Rating: 68 SCFM, For Use With: P-Style, Pkg Qty: 2, Package Type: Card No. S-1807: Design: P-Style, Thread Size: 3/8"...

S-727 Milton M-Style Plug SKU # 582925M-Style, hardened steel plated plug. Rust resistant. Basic flow size: 40 SCFM (standard cubic feet per minute). Complies with military specifications MIL-C-4109. Interchangeable with all manufacturers who comply with the dimensional requirements of military specification MIL-C-4109. No. S-727: Design: M-Style, Thread Size: 1/4" Male NPT, Material: Steel-Plated, Pressure Rating: 300 psi, Air Rating: 40 SCFM, Pkg Qty: 2, Package Type: Card No. S-728: Design:...

S-659 Full Swivel Hose End SKU # 582832Full 360 deg. swivel hose ends help eliminate kink and twisted air lines, steel construction, black oxide finish. 1/4" NPT Male end x 1/4" NPT Female swivel end. No. S-659: Design: Full Swivel, Thread Size: 1/4" MPT x 1/4" FPT, Material: Steel Black Oxide, For Use With: 1/4" Thread

S-1837 Milton H-Style Plug SKU # 583087H-style industrial interchange series. Plugs are case hardened steel-plated to resist rust. 2 per package. For use with shop air. No. S-1837: Design: H-Style, Thread Size: 3/8" NPT Male, Material: Steel-Plated, For Use With: H-Style No. S1838: Design: H-Style, Thread Size: 3/8" NPT Female, Material: Steel-Plated, For Use With: H-Style No. S-1839: Design: H-Style, Thread Size: 1/4" NPT Male, Material: Steel-Plated, For Use With: H-Style ...

S-777 Milton 1/4 In. Body Series A-Style Plug SKU # 583005A-Style plugs are case hardened steel and plated to resist rust. Plug has a maximum inlet pressure of 300 pound per square inch. No. S-777: Design: A-Style, Thread Size: 1/4" MPT, Material: Steel-Plated, For Use With: A-Style No. S-778: Design: A-Style, Thread Size: 1/4" MPT, Material: Steel-Plated, For Use With: A-Style

S-1807 Milton P-Style Plug SKU # 570668P-style plug constructed of case hardened steel plated to resist rust. Maximum temperature: 250 degrees Fahrenheit. Air flow: 68 SCFM (standard cubic feet per minute). Maximum inlet pressure: 300 psi (pounds per square inch). No. S-1809: Design: P-Style, Thread Size: 1/4" MNPT, Material: Case Hardened Steel, Pressure Rating: 300 psi, Air Rating: 68 SCFM, For Use With: P-Style, Pkg Qty: 2, Package Type: Card No. S-1807: Design: P-Style, Thread Size: 3/8"...

S-745 AMT Style 3-Way CouplerAMT style 3-way female coupler. Ideal for shops where multiple couplers are used. No. S-745: Design: AMT Style, Type: Push-Type with Drag Guard, Thread Size: 1/4" FNPT, Material: Heavy-Duty Brass, Pressure Rating: 300 psi, Air Rating: 42 SCFM, Pkg Qty: 1, Package Type: Card

S-1816 G-Style CouplerG-style coupler. Requires over 60 SCFM (standard cubic feet per minute) air flow. No. S-1815: Design: G-Style, Thread Size: 1/2" FNPT, Material: Steel, Pressure Rating: 300 psi, Air Rating: 99 SCFM, Maximum Temperature: 250 F, For Use With: G-Style, Pkg Qty: 1, Package Type: Card No. S-1816: Design: G-Style, Thread Size: 1/2" MNPT, Material: Steel, Pressure Rating: 300 psi, Air Rating: 99 SCFM, Maximum Temperature: 250 F, For Use With: G-Style, Pkg Qty: 1, Package Type:...

S-646 Brass Hex Nipple Coupler SKU # 582816Miltons Brass Male hex nipple coupler is finished with male national pipe thread. Its brass material ensures its durability. No. S-646: Design: Hex, Thread Size: 1/4" NPT, Material: Brass, Pressure Rating: 300 psi, Air Rating: 40 SCFM, Pkg Qty: 2, Package Type: Card No. S-647: Design: Hex, Thread Size: 3/8" NPT, Material: Brass, Pressure Rating: 300 psi, Pkg Qty: 2, Package Type: Card

S-1803 P-Style CouplerP-style coupler. Bodies have 8 locking balls for better retention of plug. No. S-1803: Design: P-Style, Thread Size: 1/4" FNPT, Material: Heavy-Duty Steel, Pressure Rating: 300 psi, Air Rating: 68 SCFM, Maximum Temperature: 250 F, For Use With: P-Style, Pkg Qty: 1, Package Type: Card No. S-1805: Design: P-Style, Thread Size: 3/8" FNPT, Material: Heavy-Duty Steel, Pressure Rating: 300 psi, Air Rating: 68 SCFM, Maximum Temperature: 250 F, For Use With: P-Style, Pkg Qty: 1,...

S-1805 P-Style CouplerP-style coupler. Bodies have 8 locking balls for better retention of plug. No. S-1803: Design: P-Style, Thread Size: 1/4" FNPT, Material: Heavy-Duty Steel, Pressure Rating: 300 psi, Air Rating: 68 SCFM, Maximum Temperature: 250 F, For Use With: P-Style, Pkg Qty: 1, Package Type: Card No. S-1805: Design: P-Style, Thread Size: 3/8" FNPT, Material: Heavy-Duty Steel, Pressure Rating: 300 psi, Air Rating: 68 SCFM, Maximum Temperature: 250 F, For Use With: P-Style, Pkg Qty: 1,...
