Eaton Corporation

CHF115CS Eaton CHF Circuit BreakerCircuit breaker for use in CH load centers. Features a trip flag indicator. 120 volt/240 volt, 10,000 AIC (amps interrupting capacity). UL (Underwriter's Laboratories) listed.

BR250 Eaton BR Circuit BreakerCircuit breaker for use in NLC load centers. Plug-on type featuring a common trip. 120 volt/240 volt. For use in BR series panels. UL (Underwriter's Laboratories) listed. No. BR115: Amperage: 15A, Number of Poles: 1-Pole, Interruption Type: Standard Trip, Voltage: 120V/240V, Frame Size: 1-Space, Breaker Size: 1 In., Mount Type: Plug-In, Wire Size: #14-4 AWG, UL Listed: Yes, Pkg Qty: 1 No. BR120: Amperage: 20A, Number of Poles: 1-Pole, Interruption Type: Standard...

BR24L70RP Eaton Load CenterMain Lug load center designed for service entrance equipment. Main Lugs Only. Single-phase, 3-wire, flush or surface mount. Solid neutral bar and cover included. Optional ground bar kits must be ordered separately. Load centers that accept BD and BQ type circuit breakers have a notched bus bar. UL listed.

DP221NGB Eaton Safety SwitchPlug fuse general-duty safety switch designed for residential and commercial applications where economy is a prime consideration. Typical uses are heating, lighting, air conditioning and appliances. Plug fuses not included. UL listed. No. DP111NGB: Series: DP, Amperage: 30A, Fuse Type: Plug, Type: Indoor, Voltage: 120V, Number Of Wires: 2 Wires, Phase: Single, Number Of Poles: 1 Pole, UL Listed: Yes, Pkg Qty: 1 No. DP221NGB: Series: BR, Amperage: 30A, Type: Indoor,...

BRN115DF Eaton BR Short Body Dual Function BreakerDual purpose arc fault/ground fault circuit breaker. Plug-on, single pole, 10 kAIC. LED diagnostics included. Short body design. No. BRN115DF: Amperage: 15A, Number of Poles: 1-Pole, Interruption Type: CAFCI/GFCI, Voltage: 120V, Frame Size: 1-Space, Breaker Size: 1 In., Mount Type: Plug-In, Wire Size: #14-4 AWG, UL Listed: Yes, Pkg Qty: 1, Package Type: Box No. BRN120DF: Amperage: 20A, Number of Poles: 1-Pole, Interruption Type: CAFCI/GFCI,...

BR115AF Eaton BR Arc Fault BreakerAFCI (arc fault circuit interrupter). Reduces fire hazards in electrical circuits by reducing the effects of high current arcing faults and detects persistent low current arcing faults. Trips to center position, interrupt rating 10 kAIC. Single pole, 1 space required. 120 volts. For BR series panels. UL (Underwriter's Laboratories) listed. No. BR115AF: Amperage: 15A, Number of Poles: 1-Pole, Interruption Type: AFCI, Voltage: 120V, Frame Size: 1-Space, Breaker...

GFCB120. GFCB, ground fault circuit interrupter. Class A ground fault and branch overcurrent protector. Single pole, 1 space required. 120V. For BR series panels. UL listed. No. GFCB115: Amperage Rating: 15A, Type: Ground Fault, Number of Poles: 1 Pole, Voltage Rating: 120/240V, Frame Size: 1 Space, Wire Size: #14-4 (Copper, Aluminum), UL Listed?: Yes No. GFCB120: Amperage Rating: 20A, Type: Ground Fault, Number of Poles: 1 Pole, Voltage Rating: 120V, Frame Size: 1 Space, Wire Size: #14-4...

BR2020B100V Eaton BR Value Pack Main Breaker Load CenterBR series value pack offers a value mix of products for a load center project. Includes (5) BR120 circuit breakers and (1) BR230 circuit breakers. Service entrance rated. Single phase, 3-wire, 10,000 AIC, combination mount, indoor use only. Cover included. UL (Underwriter's Laboratories) listed. No. BR2020B100V: Series: BR, Amperage: 100A, Number Of Spaces: 20 Spaces, Max Number of Circuits: 20 Circuits, Voltage: 120V/240V, Enclosure...

BR2040B200 Eaton BR Main Breaker Load CenterMain breaker load center designed for service entrance equipment. Main Breaker Installed. Single-phase, 3-wire, flush or surface mount. Solid neutral bar and cover included. Optional ground bar kits must be ordered separately. Load centers that accept BD and BQ type breakers have a notched bus bar. UL listed. No. BR816B100: Series: BR, Amperage: 100A, Number Of Spaces: 8 Spaces, Max Number of Circuits: 16 Circuits, Voltage: 120V/240V, Enclosure Type:...

RH150P Eaton Conduit HubConduit hub compatible with BR series equipment. Ideal to use to create a watertight seal between the meter breaker panel and the conduit holding the wire. No. DS100H1P: Conduit Size: 1", Material: Aluminum, Type: BR, Width: 3.0", Length: 2.75 ", Thickness: 1.25", Pkg Qty: 1, Package Type: Box No. RH125P: Conduit Size: 1-1/4", Material: Aluminum, Type: BR, Width: 3.5", Length: 4", Thickness: 1.5", Pkg Qty: 1, Package Type: Box No. DS125H1P: Conduit Size: 1-1/4",...

BRP40B200 Eaton BR Plug-On Neutral Load CenterSingle-phase, plug-on neutral, main circuit breaker load center. Suitable for indoor use only. Includes NEMA Type 3R cover. No. BRP20B200: Series: BR, Amperage: 200A, Number Of Spaces: 20 Spaces, Max Number of Circuits: 40 Circuits, Voltage: 120V/240V, Enclosure Type: Indoor, Phase: Single, Wire Size: #2 AWG to 300 kcmil, UL Listed: Yes, Pkg Qty: 1, Package Type: Box No. BRP30B200: Series: BR, Amperage: 200A, Number Of Spaces: 30 Spaces, Max Number...

BR48L125RP Eaton Load CenterMain Lug load center designed for service entrance equipment. Main Lugs Only. Single-phase, 3-wire, flush or surface mount. Solid neutral bar and cover included. Optional ground bar kits must be ordered separately. Load centers that accept BD and BQ type circuit breakers have a notched bus bar. UL listed.

BR612L125SDP Eaton Load CenterMain Lug load center designed for service entrance equipment. Main Lugs Only. Single-phase, 3-wire, flush or surface mount. Solid neutral bar and cover included. Optional ground bar kits must be ordered separately. Load centers that accept BD and BQ type circuit breakers have a notched bus bar. UL listed.

BQ220220 Eaton BQ Quadplex Circuit BreakerBQ quadplex circuit breaker for use in load centers with notched bus bars. Allows 2 options for use: (2) 2 pole or (1) 2 pole and (2) 1 pole breakers in 2 spaces. 120 volt/240 volt. For use in BR series panels. UL (Underwriter's Laboratories) listed. No. BQ220220: Amperage: 20A/20A, Number of Poles: 4-Pole, Interruption Type: Standard Trip, Voltage: 120V/240V, Frame Size: 2-Space, Breaker Size: 2 In., Mount Type: Plug-In, Wire Size: #14-4 AWG, UL...

BR230 Eaton BR Circuit BreakerCircuit breaker for use in NLC load centers. Plug-on type featuring a common trip. 120 volt/240 volt. For use in BR series panels. UL (Underwriter's Laboratories) listed. No. BR115: Amperage: 15A, Number of Poles: 1-Pole, Interruption Type: Standard Trip, Voltage: 120V/240V, Frame Size: 1-Space, Breaker Size: 1 In., Mount Type: Plug-In, Wire Size: #14-4 AWG, UL Listed: Yes, Pkg Qty: 1 No. BR120: Amperage: 20A, Number of Poles: 1-Pole, Interruption Type: Standard...

CH2L70SP Eaton Mainlug Load CenterSingle-phase, 3-wire; flush, surface, or combination mount. Cover included. Straight-in wiring, top or bottom. Pre-attached neutral bonding strap. Solid copper bus and branch fingers. 120/240V AC; 10,000 AIC. UL listed. No. CH2L40SP: Series: CH, Amperage: 40A, Number Of Spaces: 2 Spaces, Max Number of Poles: 2 Poles, Enclosure Type: Indoor, Mount Type: Surface, Wire Size: #14 To 6, Voltage: 120V/240V, Phase: Single, Height: 9.5", Width: 4.5", Depth: 3.13", UL...

ARP00005CH15 Eaton HubRemovable hub for use when installing meter sockets with overhead service. No. ARP00004CH12: Size: 1-1/4", Pkg Qty: 1, Package Type: Box No. ARP00005CH15: Size: 1-1/2", Pkg Qty: 1, Package Type: Box No. ARP00006CH2: Size: 2", Pkg Qty: 1, Package Type: Box

CH270 Eaton CH Circuit BreakerCircuit breaker for use in CH load centers. 120 volt/240 volt, 10,000 AIC (amps interrupting capacity). UL (Underwriter's Laboratories) listed. No. CH260CS: Amperage: 60A, Number of Poles: 2-Pole, Interruption Type: Standard Trip, Voltage: 120V/240V, Frame Size: 2-Space, Breaker Size: 1-1/2 In., Mount Type: Plug-In, Wire Size: #14-2 AWG, UL Listed: Yes, Pkg Qty: 1, Package Type: Clamshell No. CH260: Amperage: 60A, Number of Poles: 2-Pole, Interruption Type:...

CHFGFT120 Eaton CH Self Test GFCI BreakerEaton single-pole, GFCI (ground fault circuit interrupter) breaker. Features a 10 kAIC (kilo amperes interrupting capacity) rating. Equipped with mechanical flag for trip indication. Ideal for applications near water such as kitchens, bathrooms, swimming pools, hot tubs, and outdoor receptacles. No. CHFGFT115: Amperage: 15A, Number of Poles: 1-Pole, Interruption Type: GFCI, Voltage: 120V/240V, Frame Size: 1-Space, Breaker Size: 3/4 In., Mount Type:...

BR1224L125 Eaton Load CenterMain Lug load center designed for service entrance equipment. Main Lugs Only. Single-phase, 3-wire, flush or surface mount. Solid neutral bar and cover included. Optional ground bar kits must be ordered separately. Load centers that accept BD and BQ type circuit breakers have a notched bus bar. UL listed.

BR1224L200 Eaton Load CenterMain Lug load center designed for service entrance equipment. Main Lugs Only. Single-phase, 3-wire, flush or surface mount. Solid neutral bar and cover included. Optional ground bar kits must be ordered separately. Load centers that accept BD and BQ type circuit breakers have a notched bus bar. UL listed.

CHFCAF115 Eaton CH Combination Arc Fault BreakerAFCI (arc fault circuit interrupter) breaker. Fireguard combination AFCI, 1-pole. Trips to the off position, eliminating nuisance callbacks. Features a thermal magnetic trip curve that avoids nuisance tripping on mild overloads, but reacts almost instantaneously to sever short-circuit conditions. 10kAIC. 120 volt/240 volt. No. CHFCAF115: Amperage: 15A, Number of Poles: 1-Pole, Interruption Type: CAFCI, Voltage: 120V/240V, Frame Size: 1-Space,...

BRAFGF115 Eaton BR Self Test Dual Function BreakerDual purpose AFCI (arc fault circuit interrupter)/GFCI (ground fault circuit interrupter) for residential and light commercial applications. Provides one device for both AFCI and GFCI protection. Allows single point of reset. Complete protection for the entire circuit, including home-runs. Reduces unwanted tripping from interaction with devices or appliances. Features an integral LED (light emitting diode) that indicates 7 different trip...

BRFPP Eaton 1" Breaker Filler PlateFills opening in BR load center covers when twist-out has been removed. 5-pack filler plate includes (5) 1" filler plates. No. BRFPP: Type: BR Load Center, Pkg Qty: 5, Package Type: Bag
